用途及特點
本機床是集國內同類機床之優點,重新研制開發的新一代自動高效活塞環內徑倒角機床,特別適用于大缸徑、球鐵活塞環的內孔倒角。整機由數控系統控制,內刀桿滑臺采用伺服驅動,工件轉速為變頻調速,速度顯示在系統界面;進給速度、轉速、倒角深度等加工參數在均在系統變量中設置,充分保證倒角精度及表面粗糙度。本機配備有理環機,能將加工好的環按順序全部整理好,可實現一人多機作業,深受廣大使用者青睞。

DX15-2 Piston Ringl.D.Chamfering Machine
The application and featureofthemachine
Piston ring lD. chamfering machine, which is new development production and getsadvantages from similar machines, is used to the Internal hole chamfer of large-bore and nodularcast iron piston rings. lt's a new generation of automatic and efficient machine, which iscompletely controlled by CNC system. Chamfer angles can get good roughness and shapeaccuracy because the cutter bar carriage is driven by a servo motor. The rotating ofthe ringsis control by the inverter and frequency motor, Rotating speed can be displayed on themachine control panel.
Feed rate ofthe cutter bar, rotatingspeed ofthe rings and cutting depth can be set by variablesin CNC system. The ring aligner is provided for unloading and feeding cylinder for loading, so one-man-multi-machineis feasible, which is well received by the user.
