用途及特點
本機床是一種新開發的產品,用于加工活塞環的外圓面。完全由數控系統控制,并實現自動裝卸料。它能有效地車削各種表面,如圓錐形、油腔等。由于采用了數控和交流伺服驅動單元,環件的外徑加工可以獲得良好的粗糙度和形狀精度。
機床的加工、上下料循環由程序執行。工件箱電機采用變頻控制,實現無級調速。進給速度、主軸轉速和切削深度可以通過系統中的變量來設定。裝料機構為液壓驅動,卸料由氣動機械爪完成,機床具有較高的定位精度、報警顯示、自診斷功能和可靠性。

DX26 Piston RingAuto 0.D.Turning Machine
The application and feature ofthemachine
Auto O.D. Turning Machine, which is new development production, is used to process O.D. ofpiston rings. lt is completely controlled by CNC system, and the rings loading and unloading isautomatic. Different surface of rings such as conical-shape and oil-slotted can be processed efficiently.The 0.D. of rings can get good roughness and shape accuracy because the machine has the numericalcontroland ACservo drive unit.
The processing, loading and unloading cycles of the machine are execute by NC programs.The headstock is speed variation because its motor is controlled by VFD, The feed rate, spindlespeed and cutting depth can be set by variables in CNC system. Loading device is driven by thehydraulic unit and unloading is driven by the pneumatic claw. The machine has the highpositioning accuracy,alarminterface,selfdiagnosticfunction and reliability.
